| Part No. | Rope Size | Dimensions(inch) | Weight/pcs | |||||
| inch | A | B | C | D | E | F | kg | |
| KBS464008 | 5/16 | 2-1/8 | 1-5/16 | 1-1/2 | 7/8 | 1/2 | 5/16 | 0.065 |
| KBS464009 | 3/8 | 2-1/2 | 1-1/2 | 1-7/8 | 1 | 9/16 | 13/32 | 0.091 |
| KBS464011 | 7/16 | 2-7/8 | 1-1/2 | 2-1/8 | 1-1/8 | 11/16 | 1/2 | 0.12 |
| KBS464013 | 1/2 | 3-1/8 | 1-3/4 | 2-5/16 | 1-1/4 | 13/16 | 9/16 | 0.16 |
| KBS464014 | 9/16 | 3-1/8 | 1-3/4 | 2-5/16 | 1-1/4 | 13/16 | 9/16 | 0.172 |
| KBS464016 | 5/8 | 3-7/8 | 2-5/16 | 2-15/16 | 1-5/8 | 7/8 | 5/8 | 0.26 |
| KBS464017 | 11/16 | 4-1/4 | 2-5/8 | 3-1/8 | 1-3/4 | 1-1/8 | 3/4 | 0.34 |
| KBS464019 | 3/4 | 4-7/8 | 2-7/8 | 3-5/8 | 2 | 1-1/8 | 13/16 | 0.45 |
| KBS464022 | 7/8 | 4-1/4 | 3-1/4 | 4 | 2-1/4 | 1-1/4 | 7/8 | 0.62 |
| KBS464024 | 15/16 | 5-3/4 | 3-5/8 | 5-11/16 | 2-1/2 | 1-5/16 | 1 | 0.8 |
| KBS464025 | 1 | 6-3/8 | 4-1/4 | 4-11/16 | 2-3/4 | 1-3/8 | 1-1/16 | 0.95 |
| KBS464029 | 1-1/8 | 7 | 4-3/8 | 5-1/4 | 3 | 1-1/8 | 1-1/8 | 1.27 |
| KBS464032 | 1-1/4 | 7-3/4 | 5-1/4 | 6 | 3-3/4 | 1-5/8 | 1-5/16 | 1.6 |
| KBS464035 | 1-3/8 | 9 | 6 | 6-7/8 | 4-1/8 | 1-7/8 | 1-1/2 | 2.35 |
| KBS464038 | 1-1/2 | 10 | 6-1/2 | 7-3/4 | 4-1/2 | 2-1/8 | 1-5/8 | 3.3 |
| KBS464041 | 1-5/8 | 10 | 6-1/2 | 7-3/4 | 4-1/2 | 2-3/16 | 1-7/8 | 3.35 |
| KBS464044 | 1-3/4 | 11-1/4 | 7 | 9 | 5 | 2-1/4 | 2 | 6.25 |
| KBS464048 | 1-7/8 | 12-1/4 | 7-/2 | 9-3/4 | 5-1/4 | 2-5/8 | 2-3/8 | 7.7 |
| KBS464051 | 2 | 13 | 8 | 10-1/8 | 5-1/2 | 2-2/4 | 2-1/8 | 8.05 |
| KBS464054 | 2-1/8 | 13 | 8 | 10-1/8 | 5-1/2 | 2-3/4 | 2-1/2 | 8.3 |
| KBS464057 | 2-1/4 | 14 | 8-1/2 | 10-5/8 | 5-3/4 | 3 | 2-5/8 | 8.6 |
| KBS464064 | 2-1/2 | 16-1/4 | 9-1/2 | 12-1/4 | 6-1/4 | 3-3/4 | 2-3/4 | 17 |
