Part No. | Rope Size | Dimensions(mm) | Pin Dia | |||||||
mm | L | D | D1 | R | B | t | r | h | d(mm) | |
KJIS024 | 20 | 136 | 105 | 42 | 112 | 29 | 2.5 | 13 | 10 | 36 |
KJIS026 | 22.4 | 144 | 110 | 42 | 120 | 31 | 2.5 | 13.5 | 10 | 36 |
KJIS028 | 24.25 | 156 | 120 | 50 | 131 | 33 | 2.5 | 14.8 | 11.5 | 42 |
KJIS030 | 26 | 166 | 130 | 50 | 137 | 35 | 2.5 | 15.5 | 13 | 42 |
KJIS032 | 28 | 180 | 140 | 50 | 148 | 38 | 3 | 16.5 | 14.5 | 42 |
KJIS034 | 30/31.5 | 186 | 145 | 55 | 154 | 40 | 3 | 17.5 | 13.5 | 48 |
KJIS036 | 32/33.5 | 196 | 150 | 55 | 164 | 42 | 3 | 19 | 13.5 | 48 |
KJIS045 | 35/35.5/40 | 242 | 190 | 75 | 198 | 52 | 4 | 22.5 | 19.5 | 64 |
