Swaged Soft Loop Sling
| Rope Dia.d | Soft loop dimension(mm) | MBL(t) | WLL(t) | Rope Dia.d | Soft loop dimensions(mm) | MBL(t) | WLL(t) | ||
| (mm) | A | B | (mm) | A | B | ||||
| 6 | 120 | 60 | 1.6 | 0.3 | 48 | 960 | 480 | 104.6 | 20.9 |
| 8 | 160 | 80 | 2.9 | 0.6 | 50 | 1000 | 500 | 112.9 | 22.6 |
| 10 | 200 | 100 | 4.5 | 0.9 | 52 | 1040 | 520 | 122.1 | 24.4 |
| 12 | 240 | 120 | 6.5 | 1.3 | 54 | 1080 | 540 | 132.3 | 26.4 |
| 14 | 280 | 140 | 8.9 | 1.8 | 56 | 1120 | 560 | 141.3 | 28.3 |
| 16 | 320 | 160 | 11.6 | 2.3 | 58 | 1160 | 580 | 152.3 | 30.5 |
| 18 | 360 | 180 | 14.7 | 2.9 | 60 | 1200 | 600 | 162.4 | 32.5 |
| 20 | 400 | 200 | 18.1 | 3.6 | 64 | 1280 | 640 | 178 | 35.6 |
| 22 | 440 | 220 | 21.8 | 4.4 | 68 | 1360 | 680 | 201 | 40.2 |
| 24 | 480 | 240 | 26.1 | 5.2 | 72 | 1440 | 720 | 224.8 | 45 |
| 26 | 520 | 260 | 30.6 | 6.1 | 76 | 1520 | 760 | 250.5 | 50.1 |
| 28 | 560 | 280 | 35.4 | 7.1 | 80 | 1600 | 800 | 277.2 | 55.4 |
| 30 | 600 | 300 | 40.7 | 8.1 | 84 | 1680 | 840 | 305.6 | 61.1 |
| 32 | 640 | 320 | 46.3 | 9.3 | 88 | 1760 | 880 | 335.9 | 67.2 |
| 34 | 680 | 340 | 52.3 | 10.5 | 92 | 1840 | 920 | 367.1 | 73.4 |
| 36 | 720 | 360 | 58.6 | 11.7 | 96 | 1920 | 960 | 400.1 | 80 |
| 38 | 760 | 380 | 65.3 | 13.1 | 100 | 2000 | 1000 | 434.1 | 86.8 |
| 40 | 800 | 400 | 72.3 | 14.5 | 104 | 2080 | 1040 | 469 | 93.8 |
| 42 | 840 | 420 | 79.8 | 16 | 108 | 2160 | 1080 | 505.7 | 101.1 |
| 44 | 880 | 440 | 87.6 | 17.5 | 110 | 2200 | 1100 | 524.9 | 105 |
| 46 | 920 | 460 | 95.4 | 19.1 | 120 | 2400 | 1200 | 624.6 | 124.9 |
